AERINOS ProfiSens IOT

Introduction

AERINOS® ProfiSens is a local area wireless IOT platform. It comprises wireless sensor nodes and a 3G Data Concentrator/ Gateway. Using ProfiSens, you can deploy anywhere your own IOT network. The battery powered, wireless End nodes, offer reliable communication and outdoor enclosures to satisfy a variety of measurement and monitoring applications. The acquired sensor data wirelessly transmits to the data concentrator with 3G, GSM/GPRS connectivity, which forwards data files to an FTP server and alarm SMS to predefined users.
The coverage of the wireless network can reach a radius of 1-6 km (Line of sight). The platform is available for the 433 MHz license free band and optional for the 868 MHz and 915 MHz bands.
The wireless network uses a proprietary protocol with bidirectional communications. The sensor nodes are frequently synchronized by the data concentrator in order to achieve real time data collection with a fixed update rate of 5 minutes. Data concentrator and sensor end nodes support autonomous battery powered operation and provide options for external power supply.

Devices

Applications

• Agricultural Monitoring
• Tank level monitoring
• Water/wastewater
• Structural Engineering
• Oil & Gas
• Environmental Monitoring
• Weather Monitoring
